Overview
FS-PT500HLV1520FHVIR155R High Definition Dual-sensor Night Vision System is the night vision product with independent intellectual property right, which integrates uncooled thermal imaging camera, color camera and high speed pantilt. It adopts thermal imaging with features such as clear image, good concealment and being not limited by light source. Color camera and thermal imaging camera integrate effectively, the day vision distance of color camera 8-10km,the detection distance to human of thermal imaging camera 6km, realizing day and night continuous monitoring.
Product Features
• Long range visible light camera and thermal imaging camera integrating design, realizing day and night monitoring
• Variable speed pantilt, realizing all-around, no-blind-corner monitoring and high precision location
• Integrated intelligent temperature controlling system, making sure electronic device inside the housing work normally 24/7
• Passive infrared thermal imaging, good concealment, not easy to be perceived
• Professionally designed housing, artistic, light, solid, high temperature resistant, anti-corrosion, water-proof, anti-acid rain
• Low power consumption, little heat generation, stable working performance
Specifications
| Monitoring distance | Visible light camera | 4500m |
| Thermal camera | Object | Human (1.8m×0.5m) | Vehicle (2.3m×2.3m) |
| Detection distance | 4200m | 12000m |
| Recognition distance | 1390m | 3000m |
| Identification distance | 700m | 1500m |
| Visible light camera lens | Focal length | 12.5~750mm |
| Iris | F3.8~F22.C |
| Auto iris | DC drive |
| FOV | 28.8°~0.5° |
| Fog penetrating | support |
| Focus control | Electronic,Auto |
| Visible light camera | Sensor | 1/1.8''Progressive Scan CMOS |
| Color mode | ICR double filter, day＆night switch |
| Shutter speed | Auto and manual adjustment |
| Camera control | Auto gain control, auto white balance,
supporting manual and auto day＆night mode switch |
| Fog penetrating | Open /Close is optional |
| WDR | Open/Close is optional |
| BLC | Open/Close is optional; range is optional |
| ROI | Supporting Open/Close, range is optional |
| Back focus fine adjustment | Supporting, can remotely debug |
| Noise reduction | 3D digital noise reduction |
| Code format | H.264/MJPEG/MPEG4 |
| Video resolution | 1080p, supporting three stream |
| Video code rate | 32Kbps~16Mbps |
| Video frame rate | 50Hz:25fps(1920×1080),25fps (1280×720) 60Hz:30fps(1920×1080),30fps (1280×720) |
| Title overlay | Logo, date, time |
| Image adjustment | Brightness, contrast, saturation, sharpness etc. |
| Network protocol | TCP/IP/RTP/RTSP/HTTP/DNS/DDNS/DHCP/FTP/NTP/PPPOE/SMTP/UPNP |
| Features | Supporting heartbeat, video cover, code protection |
| Infrared lens | Focal length | 30～150mm,5x optical zoom |
| FOV | 4.2°×3.3°~20.6°×165.5° |
| Spatial resolution | 0.11~0.57mrad |
| Lens control | Electronic zoom/focus,Auto focus |
| Detector | Detector type | Uncooled FPA |
| Effective pixel | 640×512 |
| Spectrum range | 8～14μm |
| NETD | 50mK@F1.0, 300K |
| Frame frequency | 25Hz |
| Nonuniformity correction | Auto/ manual/ background correction |
| Image process | DDE |
| Video output | PAL/NTSC |
| Ball type Pan/tilt | Pan angle | 360°, continuous rotation |
| Tilt angle | -45°~+45° |
| Pan speed | 0.01°~80°/s |
| Tilt speed | 0.01°~60°/s |
| Preset | 128 |
| Preset precision | ≤0.05° |
| Auto cruise | 2 path, 64 presets each path |
| Auto line scan | 1 path |
| Communication protocol | Pelco-D、Pelco-P optional |
| Bit rate | 2400/4800/9600/19200 bps optional |
| Anti-lightning | Power supply 4000V, video signal 2000V |
| Gyro Stabilizer(optional) | feature | 2-Axis,Fiber optic gyroscope |
| Tracking (Optional) | Features | Programmable two-axis platform drive control (PID),
support for rate control; built-in multiple tracking algorithms |
| Tracking algorithm | Correlation tracking algorithm,
template matching tracking algorithm, color tracking algorithm |
| Min target size | 3×6 pixels |
| Max target size | 200×100 pixels |
| Number of motion detection targets | 5 |
| Overall unit interface | Power interface | DC30V |
| Network interface | 1×10Base-T/100Base-TX RJ45 |
| Others | RS422 |
| Environment indicators | Working temperature | -25℃~+55℃ |
| Storage temperature | -40℃~+65℃ |
| Protection | IP66 |
| Anti-salt fog | Comply with GB/T2423.17-2008 |
| Power supply | Overall unit power supply | DC30V, equipped with AC220V～DC30V/10A wide range water-proof power adapter |
| Physical features | Installation | Outdoor pedestal mounted |
Size (Only For Reference)
