Features
• Integrate infrared detection system, video recording system, high precision transmission system and gyro image stabilizing system;
• High precision two axis gyro stabilization technology;
• CCTV camera wavelength extend infrared enhancement technology;
• High performance parallel process ability, real-time functional ARM+FPGA hardware process platform;
• Modularization and parallelization real-time embedded system;
• Real-time video OSD;
• High intensity, high precision, super-low resistance design;
• Spherical design with strong wind resistance, all-metal shell;
• Special reinforced design, suitable for UAV, aircraft, vehicle and vessel;
• Low power consumption and heat, stable performance;
• Video camera lens with heater enable normal starting under low temperature;
• Position lock after power off to protect thermal lens;
• GPS function;
• Two axis stabilization, separated control;
• Full aluminum alloy shell for anti-salt-fog;
Specifications
| Distance | Thermal camera | Target | Human（1.8m×0.5m） | Vehicle（2.3m×2.3m） |
| detection | 1400m | 4000m |
| recognition | 350m | 1000m |
| identification | 170m | 500m |
| Visible | 1000m |
| Platform | Two axis stabilization (Target-tracking optional ) |
| Rotation range | Horizontal | 360° horizontal rotation |
| Vertical | +90° ～-90° |
| Rotation speed | Orientation and vertical angle speed | ≥100°/s |
| Orientation and vertical angle accelerated speed | ≥60°/s2 |
| Precision | stabilization precision | ≤1mrad（RMS） |
| optical axis overlap ratio | ≤2 pixel |
| Visible CCTV camera | Sensor type | ¼ EXview HAD CCD |
| Valid pixel | 440000 pixel |
| Horizontal resolution | 530TVL(color), 570TVL(black&white) |
| Focal length | 3.4～122.4 mm, 36X optical zoom |
| Iris | F1.6～F4.5 |
| FOV | 57.8°(wide)～1.7°(tele) |
| Focus | auto/manual/zoom trigger |
| Lowest illumination | 0.2Lux/F1.4(color);0.001Lux/F1.4(black&white) |
| White balance | Auto/auto-tracking/indoor/outdoor/trigger/manual |
| SNR | ≥50db |
| Thermal camera | Detector | Uncooled microbolometer focal array (Vox) |
| Valid pixel | 640×512 |
| Spectrum range | 8～14μm |
| NETD | ≤60mK@F1.0,300K |
| Focal length | 50 mm (25/35 optional) |
| FOV | 12.4°×9.9° |
| IFOV | 0.34mrad |
| Frame rate | 50Hz |
| Image process | 4× digital zoom, pseudo color |
| Video format | PAL |
| OSD | ü Two axis status:ü Video camera zoom information;ü GPS information (optional);ü Pantilt information |
| Interface | Power supply interface | DC（direct current） |
| Others | RS422/485(Optional), 1×BNC daylight video output, 1×BNC thermal output |
| Environmental indicators | Operation temperature | -35℃～+50℃ |
| Storage temperature | -40℃～+70℃ |
| Protection grade | IP66 |
| Anti-vibration | 10～150Hz, 2g accelerated speed, 3 axial direction sweep frequency 7.5hours, meet GJB150.162A-2009 |
| Anti-impact | 150m/s², 11ms, meet GJB150.162A-2009 |
| Anti-saltfog | PH 6.5～7.2, spray fog for 48hours |
| Power supply | Operation voltage | DC18V~36V |
| Whole consumption | continuous consumption≤55W, Peak consumption≤70W; |
| Others | Weight | ≤15Kg |
| Size | 385×250×150mm |
| Installation way | lifting or base installation |
Assumptions
50% probability of achieving objective at the specified distance given a 2-degree temperature difference and 0.85/km atmospheric attenuation factor. Actual range may vary depending on camera setup, environmental conditions, user experience, and type of monitor or display used.
