Features
• Adopting continuous zooming thermal imaging technology, imaging clearly, can search in large area and recognize objectives in long distance
• Infrared detector with high temp sensitivity, with min temp resolution of 50mK
• Day and night 2 megapixels low illuminating color camera, realizing day and night continuous monitoring
• Optional auto focusing function, realizing multiple focusing mode and triggering mode
• Optional thermal imaging camera presetting function, remembering FOV of each preset bit, enhancing working efficiency
• Professionally designed shell, artistic, light, firm, anti-high temp, anti-corrosion, water proof, anti-acid rain
Technical Data
| Monitor distance | Visible light | Day vision | ≥5000m |
| Thermal Camera | Object | Human （1.8m×0.5m） | vehicle（2.3m×2.3m） |
| Detection distance | 4200m | 12000m |
| Recognition distance | 1050m | 3000m |
| Identification distance | 520m | 1500m |
| Thermal lens | Focal length | 30～150mm, 5× optical zoom |
| FOV | 4.2°×3.1°～20.6°×15.5° |
| F value | F1.0～F1.2 |
| Lens control | electric zooming, electric focusing(auto focusing optional) |
| Thermal Detector | Detector type | uncooled microbolometer focal plane array（VOX） |
| Resolution | 640×512 |
| Spectral range | 8～14μm |
| NETD | ≤50mK@F1.0,300K |
| Image processing | DDE, pseudo color |
| HD day camera lens | Focal length | 15.6～500mm |
| Auto focusing | supporting |
| HD Camera | Sensor type | 1/1.8” Progressive Scan CMOS |
| Code | H.264/MJPEG/MPEG4 |
| Video resolution | 1080P,CIF,supporting three stream |
| Video frame rate | 1～25f/s（50Hz）,1～30f/s（60Hz） |
| Pan-tilt | Carrying capacity | 50kg (top load) |
| Angle | Horizontal 360°continuous rotation,pitching: -60°～+20° |
| speed | Horizontal 0.01°～12°/s,pitching 0.01°～8°/s |
| Preset | 255 |
| Cruising | 8 paths,10 bits each path |
| Anti-lightning | 2000V |
| Interface | Power supply | AC24V |
| Network interface | 1×10Base-T/100Base-TX,RJ45 |
| Other interfaces | RS422 communication,BNC video output |
| Environment indicators | Working temp | -25℃～+55℃ |
| Storage temp | -40℃～+65℃ |
| Protection grade | IP66 |
